This model is automatic high speed continuous cartoning machine which is high performance product incorporates pneumatic-photo-electro-mechanic, each main mechanism is individually controlled by one or two sets of servos, and customer just change the data on the touch screen can do the adjustment for different size product, without manually adjustment, fully realiziing automation. It is suitable for automatic inserting ALU-PvC blister, bottle, soft tube, soft AL/AL strips and pouch into carton, also can link to matching machine to form production line.
| Encasing speed | 600 Cartons/min | |
| Carton | Quality requirement | 350g/m² Base on carton size |
| Dimension range (LxWxH) | (70-180)mm x (35-80)mm x (14-50)mm | |
| Leaflet | Quality requirement | 60-70g/m² |
| Unfolded leaflet specification | (80-300)mm x (90-180)mm | |
| Fold range | 【1-4】Fold | |
| Compressed air | Working pressure | ≥0.6Mpa |
| Air consumption | About 280-320L/min | |
| Power supply | 380V 50Hz | |
| Motor power | 15kw | |
| Machine dimension (L x W x H) | 5100mm x1850mmx2000mm | |
| Machine weight | About 5500kg | |
