JDZ-320 high-speed cartoning machine is a high-performance product of our company that integrates machinery, light, electricity and gas. The relevant technology has reached European and American standards. It has high efficiency and high-performance production capacity, and the operation and maintenance are faster and more applicable. It is used for automatic packing blister, bottles, tubes, stips and bag-like items, and can be linked with other machine to form a packaging production line.
Encasing speed | 320 Cartons/min | |
Carton | Quality requirement | 250-350g/m² (Base on carton size) |
Dimension range (L×W×H) | (70-180)mm×(35-80)mm×(14-50)mm | |
Leaflet | Quality requirement | 60-70g/m² |
Unfolded leaflet specification | (80-300)mm×(90-180)mm | |
Fold range | 【1-4】Fold | |
Compressed air | Working pressure | ≥0.6Mpa |
Air consumption | 160-200L/min | |
Power supply | 380V 50Hz | |
Motor power | 5.8kw | |
Machine dimension (L×W×H) | 4770mm×1706mm×2203mm | |
Machine weight | 3100kg |
