JD-MOC-300 Transparent Membrane Three-dimensional Packaging Machine
JD-MOC-300

Cellophane Overwrapping Machines

This machine is suitable for packing appearance decoration of big box widely used in the pharmaceutical, health care products, food, daily chemical products, electronic products. PLC human-machine interface control; film feeding system is controlled by step motor, adjustable film feeding size; the rest movement use cylinder drive, running stablely and reliablely. By supply of packaging product by conveyor belt, film feeding, folding, heat sealing and a series of actions to package goods to make packaging product to reach decoration, beautiful, anti-counterfeiting, moisture-proof effect.

Send Your Inquiry more
Parameter
Packing material /core inner size BOPP film, heat seal shrink film,PVC film Φ76mm
Packing speed 10-30 pcs/min
Packing size lenhth: 60-300mm   width: 50-250mm  thickness: 25-100mm
Power supply 220V/50HZ
Power supply 6.5KW
Machine weight 750KG
Working pressure 0.6MPA
Sealing qualitification rate >99%
Sealing breakage rate <1%
Dimension Main body 2200x 930 x2130mm
